Zio W3000 Wall Processor
IP Video Wall Processing System
Our advanced Zio® AV-over-IP encoders allow signals up to 4K UHD to be encoded, sent across a standard IP network, and decoded for display in a window on the video wall. From a simple 2x2 wall array in a lobby to multiple walls across a corporate campus, the Zio wall processor platform provides the flexibility required for any video wall application.
Decoding and display of up to 11x 2K or 2x 4K resolution IP streams
Management & control across LANs & WANs
H.264 and H.265 decoding up to 4K UHD
Scripting interface for external system control
VIEW ALL: AV-over-IP, Video Wall Processors
Overview
The Zio system offers seamless switching over the IP network infrastructure. Both dedicated and shared networks are supported.
The Zio product line includes encoder, decoder, multiviewer, and wall processor models that support 2K or 4K video over IP. Zio endpoints encode and decode video, audio, and control signals using industry standard compression.
The Zio 3000 Series IP video wall processors are flexible decoders designed to work with the S2000 Series encoders and H.264/H.265 compliant devices.
Specifications
Model: Zio 3000 Series Wall Processor
Inputs
Type
Video Stream
Connector
1x RJ-45 (GigE)
Resolution
Up to 1920 x 1080 @ 60 Hz, 3840 x 2160 @ 60 Hz
Simultaneous Streams
11x FullHD, 2 x 4K or equivalent
Audio Support
Digital (embedded video stream)
Outputs
Type
DisplayPort
Connector
4x mini-DisplayPort 1.4
Resolution
Up to 3840x2160 @60 Hz
Audio Support
Digital (embedded HDMI®) or Analog (stereo)
Physical
Dimensions (H x W x D)
1.4 x 7.0 x 7.2 inches
(36.5 x 179 x 182.9 mm)
(36.5 x 179 x 182.9 mm)
Weight
3.1 lbs / 1.4 kg
Power
100-240 VAC; 50/60 Hz, 135 W max
Streaming
Compression Format
H.264, H.265
Streaming Protocol
RTSP, Unicast/Multicast
Control
Application
Browser-based HTML5: Windows, macOS, iOS and Android
Network
Ethernet TCP/IP 10/100/1000Base-T
